Construction:

Metal housing for mounting in control panels, in conformance with DIN 40050 Type of protection IP 54, as specified in DIN50050

Dimensions:

144 x 144 x 300 mm (lxwxh)

Auxiliary voltage:

230 Vac ± 10 % 50/60 Hz

Power consumption:

About 15 VA

Attention:

If you use L-probe and O2 -probe you can ́t connect an additional Reference junction.
Thermo couple,typeK or S
Reference junction,type K or S (also mixed)
Terminal temperature (Pt 100)
External set value:analog or through serial interface

Analog Input:

O2 measuring probe, cell voltage directly or through the amplifier
O2 measuring probe and CO analyzer
CO2 analyzer
CO2 analyzer and CO analyzer
O2 probe and L-probe
O2probe, L-probeandCOanalyzer
L-probeandCOanalyzer
L-probeandCO2 analyzer
L-probe, CO2analyzerandCOanalyzer
L-probe and L-probe
O2 probe and O2 probe
CO2 analyzer and O2 probe

Optionales Zubehör:

Rel-Box
PRL-Box
Klemmleistenadapter
